Trailer horizontal diesel engine fire fighting pump Trailer horizontal diesel engine fire fighting pump Trailer horizontal diesel engine fire fighting pump

Trailer horizontal diesel engine fire fighting pump

FOB Price:
US 130-5720 / Piece
Min.Order Quantity:
1 Piece/Pieces
Supply Ability:
900 Piece/Pieces per Month
Port:
NINGBO
Place of Origin:
Zhejiang, China (Mainland)
Payment Terms:
L/C,T/T,Western Union
Brand:
YONJOU fire pump
Products Model:
IS diesel engine fire pump
Share:
  • Products Details
  • Company Profile

Quick Details

  • Brand Name: YONJOU fire pump

    Model Number: IS diesel engine fire pump

    Place of Origin: Zhejiang, China (Mainland)

Packaging & Delivery

  • Packaging Details: Standard plywood case or carton for each fire pump
  • Delivery Detail: 10 days after receiving full amount

Specifications

YonJou fire fighting pump, fire pump



Advantages

1.Directly coupled, vibration proof and low noise.

2.Same diameter of inlet and outlet .

3.NSK bearing ,which is the most famous brand in China.

4.Circulating flow cooling ensure mechnical seal long life .

5.Small foundation required that will saving construction investment by 40-60%.

6.Excellent seal that is no leakage





















































































































Application





♦ Construction ♦ Industrial ♦ Municipal
♦ Agricultural ♦ Mining ♦ Dewatering
♦ Industrial Waste ♦ Sewage ♦ Oil Field
♦ Petrochemical ♦ Paper Mills ♦ Processing









Working Conditions

Rotating speed: 3600r/min, 1800r/min, 2960r/min, 1480r/min

Medium: clean water or other liquids similar to clean water in physical and chemical properties

Medium temperature: -10 ~ 80°C,400°C available under special design

Ambient temperature: Up to 40°C

Range of capacity:1.8~2000m3/h

Range of head: up to230m

Maximum working pressure: suction pressure+head of pump≤25 bar





Pump Construction

Casing/impeller:cast iron,stainless steel,copper,bronze

Shaft:carbon steel 45#,stainless steel

Mechnical seal:graphite/silicon carbide/tungsten carbide




































































Structure Description

Compact structure, most application for modern constructions.

1.Pump casing: the spiral casing with pipe connection is designed and manufactured by the most superior bydraulic model nowadays, with inlet and outlet the same diameter. Flanges conform to GB4216.5, and are equipped with Rp1/4 or Rp 3/8 pressure testing plug.

2.Impeller: closed impeller ,no limit to rotation direction under the water temperature below 80°C and 120°C.

3.Special design of dynamic seal ring ensure well seal and reliable operation..



Motor

TEFC air-cooled squirrel cage, 3 phase asynchronous motor.

Voltage: 220V,380V,400V,415V,440V,660V(other voltage ,pls inform before order)

Frequency: 50Hz,60Hz

Insulation : IP44/IP54/IP55

Protection class: B/F

Insulation modes: B35





Packaging & Shipping

>>>Our package: strong enough during delivery by air or by sea.

Plywood Case or Steel Bar with Plastic Film
